| Module No.: | NC50 | CNC/NC: | NC |
|---|---|---|---|
| Precision: | ±0.15° | Max Bending Speed: | 80°/sec |
| Power: | Hydraulic | Machine Type: | Pipe And Tube Bending Machine |
| Highlight: | Hydraulic NC Tube Bending Machine,NC50 Tube Bending Machine,Air Conditioning NC Tube Bending Machine |
||
NC50 Hydraulic Single-Head Pipe Bender Is Suitable For Bending Air-Conditioning Pipelines
NC50 Tube Bender
NC control, touch screen panel, easy operation and high accuracy, suitable for all kinds of metal pipe and tube processing.
Product parameter:
| Main technical parameter | ||
| Max capacity | round tube/Iron tube( S=40kgf/mm ² ) | Φ50.8x3.0t |
| Round Tube/Non iron metal ( S=25kgf/mm ² ) | Φ50.8x5.0t | |
| Round tube/stainless steel tube( S=60kgf/mm ² ) | Φ50.8x1.8t | |
| Square tube/Metal tube( S=40kgf/mm ² ) | 40x40x3.0t | |
| round Bar( S=40kgf/mm ² ) | Φ25 | |
| Servo bending axis | precision | ±0.15° |
| max speed | 80°/sec |
Adapted material:steel pipe, stainless steel, copper pipe, aluminum pipe etc.
Recommended application industry:
Automobile fittings ( oil pipe for brake, muffler, seats), motorcycle, healthy equipment, air-conditioning,bicycle, steel furniture, sanitary wares and so on.
Features of pipe bending machine
1, Microcomputer control, machine operation is very stable.
2, With manual, automatic, semi-cycle, full cycle and other functions of arbitrary choice.
3, 16 angle settings (0-185 degrees arbitrary), either single or two consecutive options.
4, Mobile foot switch with three functions: automatic start, emergency stop, tight stop, high safety.
5, Large capacity cooling cycle system, make the machine run more stable.
6, Die replacement is simple and convenient for flexible production.
7, The machine head, the tube bending design is exquisite, provides the maximum bend space.
