| Module No.: | MC425CNC | Automation: | Automatic |
|---|---|---|---|
| Compressed Air: | 2.5-3.5MPa | Suitable Saw Blade: | Outer Diameter 250-370mm |
| Material Feeding Precision: | ±0.05mm | Usage: | Tube Cuttings |
| Highlight: | tube sawing machines,cnc pipe cutting machine |
||
MC425CNC- automatic tube cutting machine
Equipped with high-speed NC servo feeding and feed design, it is designed for solid bar and thick pipe sawing, non-ferrous metal sawing (NF & NFA type), and the largest pipe bar sawing outer diameter can reach 115mm. yuantai Machinery's innovative patented technology can effectively reduce labor costs and refueling time by 70%, effectively reduce production costs, enhance output efficiency and increase profitability. There is a separate tail discharge device to eliminate the hindrance of the tail
| Main parameter | ||
| Cutting capacity | round tube | Φ110 |
| Round Bar | Φ40 | |
| Square tube | 100x100/140x70 | |
| Square bar | 35x35 | |
| Suitable saw blade | High speed steel saw blade | outer diameter 250-370mm |
| Material feeding stroke | Single stroke | 6-640mm/ Outer Length 6-1000mm |
| Double stroke | 6-1280mm/ Outer Length 6-2000mm | |
| Three stroke | 6-1920mm/ Outer Length 6-3000mm | |
| Material feeding precision | ±0.05mm | |
| Working pressure | 2.5-3.5MPa | |
| machine characteristics |
| (1) Servo feeding, automatic pneumatic clamping and cutting; |
| (2) Multi-group gear transmission, suitable for heavy cutting and stable precision; |
| (3) Floating material feed, no damage to the surface of the workpiece, high accuracy |
| (4) Unique main clamp design, holding force stable and reliable; |
| (5) PLC control, touch screen control; |
| (6) Automatic lubrication of slide track, automatic stop without material; |
| (7) Configure electronic sawing quantity setting and counting; |
| (8) Sawdust centralized processing, convenient and clean. |
Applications:
Tube cuttings for Auto,motorbike,aircraft,bicycle,kids bike,fitness equipment,furniture,outdoor equipment,air conditioner,food machinery,nulcear tube such as reactor,evaporator and heat exchanger
Features
1. vertical slideway for advanced and retreat blade up and down.Cutting feed is steady and cutting tools are of long use life.High precision of saw cutting.
2. European design .multiple group of gear transmission is suitable to heavy cutting with steady precision
3. elaborate design of material feed system.The length of feed material can be set as 6-640m/mz(material feed can be divided into three times)
4. elaborate design of material feed floating system so as not to damage the surface of work piece and with high precision of material feed.
5. special main clamp design,the strength is solid
6. Slideway automatically add oil for lubricating,long use life of machine
7. Use PLC controller,no connected point,no fault and easy for maintenance
8. Cooling liquid automation circulation to ensure the smoothness of cutting surface of work piece.
9. centralized control button.Easy and simple operation.
10. Equipped with electric saw protection operation.
11. Equipped with electric saw cutting number setting and total number
12. Automatic stop when without material
13. Saw pieces are centralized for disposal which is convenient and clean
14. Digital displayer,easy fast and exact adjustment of length.
