Semi Automatic Safe Hydraulic Pipe Cutting Machine MC425HS High Accuracy

Large Image : Semi Automatic Safe Hydraulic Pipe Cutting Machine MC425HS High Accuracy

Product Details:

Place of Origin:	China
Brand Name:	YUANTAI
Certification:	CE
Model Number:	MC425HS

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiatable
Packaging Details:	Standard export wooden case or pallet package

Contact Now

Detailed Product Description

Module No.:	MC425HS	Automation:	Semi Automatic
Compressed Air:	2.5-3.5MPa	Suitable Saw Blade:	Outer Diameter 250-370mm
Material Feeding Precision:	±0.05mm	Usage:	Tube Cuttings
Highlight:	tube sawing machines , aluminum cutting machine

MC425HS- automatic tube cutting machine

main parameter
Cutting capacity	Round tube	Φ110

	Round bar	Φ40

	Square tube	100x100/140x70

	Square bar	35x35

Suitable saw blade	High speed steel saw blade	250-370mm

Working pressure	2.5-3.5MPa

machine characteristics

Vertical slide up and down knife, sawing stability accuracy is high

Reducing mechanism for efficient elimination of backlash rebound

Special design of the main clamp, clamping stability and safety;

The slide is with automatic oil lubrication system ,smooth and long life.

Cooling liquid automatic circulation

Sawdust is centralized processing

Applications:

Tube cuttings for Auto,motorbike,aircraft,bicycle,kids bike,fitness equipment,furniture,outdoor equipment,air conditioner,food machinery,nulcear tube such as reactor,evaporator and heat exchanger

Features
1. vertical slideway for advanced and retreat blade up and down.Cutting feed is steady and cutting tools are of long use life.High precision of saw cutting.
2. European design .multiple group of gear transmission is suitable to heavy cutting with steady precision
3. elaborate design of material feed system.The length of feed material can be set as 6-640m/mz(material feed can be divided into three times)
4. elaborate design of material feed floating system so as not to damage the surface of work piece and with high precision of material feed.
5. special main clamp design,the strength is solid
6. Slideway automatically add oil for lubricating,long use life of machine
7. Use PLC controller,no connected point,no fault and easy for maintenance
8. Cooling liquid automation circulation to ensure the smoothness of cutting surface of work piece.
9. centralized control button.Easy and simple operation.
10. Equipped with electric saw protection operation.
11. Equipped with electric saw cutting number setting and total number
12. Automatic stop when without material
13. Saw pieces are centralized for disposal which is convenient and clean
14. Digital displayer,easy fast and exact adjustment of length.
