Industrial Metal Sawing Machine MC325CNC Automatic Pneumatic Clamping And Cutting

Large Image : Industrial Metal Sawing Machine MC325CNC Automatic Pneumatic Clamping And Cutting

Product Details:

Place of Origin:	China
Brand Name:	YUANTAI
Certification:	CE
Model Number:	MC325CNC

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiatable
Packaging Details:	Standard export wooden case or pallet package

Contact Now

Detailed Product Description

Module No.:	MC325CNC	Automation:	Automatic
Compressed Air:	0.6MPa	Suitable Saw Blade:	Out Diameter 250-350mm
Material Feeding Precision:	±0.05mm	Usage:	Tube Cuttings
Highlight:	aluminum cutting machine , cnc pipe cutting machine

MC325CNC- automatic tube cutting machine

Main parameter
Cutting capacity	round tube	Φ110/4xΦ25

	Round Bar	Φ55

	Square tube	100x100

	Square bar	50x50

Suitable saw blade	High speed steel saw blade	out diameter 250-350mm

Material feeding stroke	Single stroke	5-650mm

	Double stroke	5-1300mm

	Three stroke	5-1950mm

Material feeding precision		±0.05mm
Compressed air use		0.6MPa

machine characteristics

Servo feeding, automatic pneumatic clamping and cutting;

Multi-group gear transmission, suitable for heavy cutting and stable precision;

Floating material feed, no damage to the surface of the workpiece, high accuracy

Unique main clamp design, holding force stable and reliable;

PLC control, touch screen control;

Automatic lubrication of slide track, automatic stop without material;

Configure electronic sawing quantity setting and counting;

Sawdust centralized processing, convenient and clean.

Applications:

Tube cuttings for Auto,motorbike,aircraft,bicycle,kids bike,fitness equipment,furniture,outdoor equipment,air conditioner,food machinery,nulcear tube such as reactor,evaporator and heat exchanger

Features
1. vertical slideway for advanced and retreat blade up and down.Cutting feed is steady and cutting tools are of long use life.High precision of saw cutting.
2. European design .multiple group of gear transmission is suitable to heavy cutting with steady precision
3. elaborate design of material feed system.The length of feed material can be set as 6-640m/mz(material feed can be divided into three times)
4. elaborate design of material feed floating system so as not to damage the surface of work piece and with high precision of material feed.
5. special main clamp design,the strength is solid
6. Slideway automatically add oil for lubricating,long use life of machine
7. Use PLC controller,no connected point,no fault and easy for maintenance
8. Cooling liquid automation circulation to ensure the smoothness of cutting surface of work piece.
9. centralized control button.Easy and simple operation.
10. Equipped with electric saw protection operation.
11. Equipped with electric saw cutting number setting and total number
12. Automatic stop when without material
13. Saw pieces are centralized for disposal which is convenient and clean
14. Digital displayer,easy fast and exact adjustment of length.
