Product Details:
Payment & Shipping Terms:
|
| Automation: | Automatic | Usage: | Tube Cutting |
|---|---|---|---|
| Cutting Angle: | 90 | Maximum Sawing Width: | 150mm |
| Maximum Sawing Height: | 150mm | Spindle Speed: | 3500rpm |
| Highlight: | 3500rpm Automatic Tube Cutting Machine,150mm Width Saw Cutting Machine,MC-400CNC Automatic Tube Cutting Machine |
||
MC-400CNC High Speed Precise Aluminum Profiles Saw Cutting Machine
MC-400CNC Pipe cutting machine
The high speed precision aluminum pipe cutting machine is mainly used for cutting aluminum and aluminum magnesium alloy extruded profiles. The high speed rotating cemented carbide saw blade is used to cut the profile quickly and accurately, and the material can be clamped quickly and automatically. Automatic feeding, automatic cutting, automatic chip removal and other functions can easily realize the cutting and processing by replacing less clamping die. Very suitable for aircraft manufacturing, automotive and other equipment aluminum profile rapid cutting processing.
Machine characteristics:
1. The equipment is a special equipment for precision cutting of low hardness non-ferrous metals such as aluminum and copper in high speed rotating condition by using cemented carbide disk saw blade as cutting tool.
2. The machine servo motor feeding system and automatic cutting function are controlled by man-machine dialogue touch screen and PLC program.
3. The feed direction is a round trip horizontal motion, which makes the cutting stable and reliable.
4. The turning direction of the saw blade is clockwise, cutting from the top of the material to the bottom, so that the cutting flow smoothly into the recovery system.
5. The saw blade is designed with a large pressure cap and a fixed screw tooth to ensure that the blade is not loosened when rotating or cutting at high speed.
6. Gas-liquid-coupled head feed mechanism to ensure the stability of the head feed movement.
7. By using patent technology, the section finish of material after cutting is 2 grades higher than that of common cutting.
8. Material cutting bilateral datum positioning, two-sided clamp clamping, to protect the profile of the material vertical.
9. Servo motor feeding system, ball wire rod transmission mechanism, so that the material cutting length accuracy guarantee ≤ 0.1mm.
Applications:
Tube cuttings for Auto,motorbike,aircraft,bicycle,kids bike,fitness equipment,furniture,outdoor equipment,air conditioner,food machinery,nulcear tube such as reactor,evaporator and heat exchanger.
The wire bending machines is largely use in different field, like cart making, spring making and so on.
