Industrial Durable Automatic Tube Cutting Machine MC-405CNC High Strength

Large Image : Industrial Durable Automatic Tube Cutting Machine MC-405CNC High Strength

Product Details:

Place of Origin:	China
Brand Name:	YUANTAI
Certification:	CE
Model Number:	MC-405CNC

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiatable
Packaging Details:	Standard export wooden case or pallet package

Contact Now

Detailed Product Description

Module No.:	MC-405CNC	Head Swivel:	90°
Operation Pressure:	25-35kg/C㎡	Servo Motor Feeding:	1KW
Material Feeding Precision:	±0.1mm	Usage:	Tube Cuttings
Highlight:	hydraulic pipe cutting machine , steel pipe cutting machine

MC-325A+EF

Main Parameter			MC-405CNC
Main Drive Motor			A:5HP/3HP 2/4.pole				4pole(std.)
			(std.)
			Low 50HZ/60HZ		5HP
			70/35rpm
			High 50HZ/60HZ
			120/60r
							2pole
							(std.)
					A:L 20RPM-70RPM
					H 35RPM-120RPM
					3200
Blade Speede
A:4 sections
B:2 sections
Frequency lnverter						5kw/7.5HP
Head Swivel			90°
Clamping Vise
Coolant Pump Motor			1/8HP 1/4HP
Max.Clamping Capacity			150
Available Saw Blade Size	Diameter	mm	HSSø250ø-405(1＂-17＂)
	Bore	mm	25.4
	Pin Holes	mm
Feeding length	Single Stroke	mm	5-650(26＂)	0-700 sevor motor

	Double Stroke	mm	5-1300(51＂)
	Three Stroke	mm	5-1950(77＂)
Servo Motor Feeding			1KW
Hydraulic Pump Motor			3HP(4P)
Operation Pressure			25-35kg/C㎡
Machine Dimensions(LWH)		mm	195013002000 220014002200
Packing Dimensions(LWH)		mm	220013002200 228016002200
		inch	87＂52＂87＂ 90＂63＂87＂
Net Weight			1400kgw(3080 lbs) 1450kgw(3190 lbs)
Gross Weight			1600kgw(3520 lbs) 1650kgw(3630 lbs)

Applications:

Tube cuttings for Auto,motorbike,aircraft,bicycle,kids bike,fitness equipment,furniture,outdoor equipment,air conditioner,food machinery,nulcear tube such as reactor,evaporator and heat exchanger

Features
1. vertical slideway for advanced and retreat blade up and down.Cutting feed is steady and cutting tools are of long use life.High precision of saw cutting.
2. European design .multiple group of gear transmission is suitable to heavy cutting with steady precision
3. elaborate design of material feed system.The length of feed material can be set as 6-640m/mz(material feed can be divided into three times)
4. elaborate design of material feed floating system so as not to damage the surface of work piece and with high precision of material feed.
5. special main clamp design,the strength is solid
6. Slideway automatically add oil for lubricating,long use life of machine
7. Use PLC controller,no connected point,no fault and easy for maintenance
8. Cooling liquid automation circulation to ensure the smoothness of cutting surface of work piece.
9. centralized control button.Easy and simple operation.
10. Equipped with electric saw protection operation.
11. Equipped with electric saw cutting number setting and total number
12. Automatic stop when without material
13. Saw pieces are centralized for disposal which is convenient and clean
14. Digital displayer,easy fast and exact adjustment of length.
