CNC80RHS+RBH Tube bender
Specification
1. tube bending machine
2. High precision,Wide application
3. CE Certification, ISO Certification
4. High performance and easy to operate
5. Digital display CNC and NC
|
machine characteristics
|
|
main technical parameter
|
|
| (1)Electical servo bending |
Max capacity |
round tube/iron tube
( S=40kgf/mm ) |
80x2.8t |
| (2)Imported servo motor and reducer |
Round tube/non iron metal tube
( S=25kgf/mm ) |
80x2.5t |
| (3)Independent R & D software system |
Round tube /stainless steel tube
( S=60kgf/mm ) |
80x1.9t |
| (4)1-6 layer die optional |
Square tube/Metal Tube
( S=40kgf/mm ) |
60x60x2.6t |
| (5)11 axis full motor type optional |
Round bar
( S=40kgf/mm ) |
38 |
| Push-bending type, bending radius7D |
Servo bending axis
|
precision
|
0.05 |
|
RBE strongly back push bending, minimum bending radius is 1D
|
max speed
|
65°/sec |
| |
Servo material feeding axis
|
precision
|
0.05mm |
| |
max speed
|
750mm/sec
RBE: 150mm/sec
|
| |
Servo tube rotate axis
|
precision
|
0.05 |
| |
max speed
|
180°/sec |
Advantages:
1. Low cost for operator training,high production effeciency and product uniformity.
2. Drived by electric servo motors.compared with hydraulic drive,it has higher stability and longer lifetime.It is unnecessary to worry about oil-leak or working temperature.
3. Gapless tube bending,with long-time high precision and processing efficiency,easy for operation.It has good compatibility.
4. Small in size,low noise level
5. Low running cost,with best cost performance for tube processing.
6. Widely used in small-diameter tube processing,for example tubes of air conditioner and oil tube for autos
Standard models:1~5 stacks,4~6 servo motors
Advanced motor:11 fully electric servo motors
FAQ
1. How to choose the pipe/tube bending machine?
You have to inform us following details:
- Max. outside diameter
- Wall thickness range
- Bending radius (CLR)
- The pipe material
- The drawings if possible
2. Do you provide any training to make sure our user can operate the machine very well?
1) We will provide detailed video and instruction book for this machine;
2) We also offer training in our factory to all the clients,and we will arrange everything for you during these days in our city,to make sure every client will be the expert in using our machine!
3. How long warranty can you provide?
Our machine warranty is one year,and we use all the stable compoenents with long working life!
And we can also send our technician to do the after-sale service in client's factory!
4. What kind of solution you can offer to make sure your pipe bending machine can do our job?
1) We will help you confirm the model of our machine according to your offered pipe information.
2) Before you start the order for this big value machine,you can offer your workpiece drawing to us.
We can design the tooling to make your products in our workshop,after you are sure that the workpiece is good,then we can confirm the order finally.
3) You can visit us to check how to bend your product before you start the order.During this period, you can also learn how to use this machine well!
