PLC Control Automated Tube Bender CNC100REMP Stainless Steel Pipe Bending Machine

PLC Control Automated Tube Bender CNC100REMP Stainless Steel Pipe Bending Machine
PLC Control Automated Tube Bender CNC100REMP Stainless Steel Pipe Bending Machine

Large Image :  PLC Control Automated Tube Bender CNC100REMP Stainless Steel Pipe Bending Machine

Product Details:
Place of Origin: China
Brand Name: YUANTAI
Certification: CE
Model Number: CNC100REMP
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiatable
Packaging Details: Standard export wooden case or pallet package
Detailed Product Description
Module No.: CNC100REMP CNC/NC: CNC
Machine Type: Pipe And Tube Bending Machine Bending Precision: 0.05
Control: PLC Control With Touch Screen Axis Servo: 11 Axis Full Motor Type Optional
Highlight:

cnc mandrel tube bender

,

mechanical pipe bending machine

CNC100REMP Tube bender



The product is controlled by PLC and hydraulically driven. The display operating system is touch-type full Chinese menu. It has prefabrication with various bending angles, Chinese subtitle display and man-machine dialogue operation. It can choose manual, semi-automatic and fully automatic operation modes. The mobile foot switch has both start and stop functions.

Hydraulic system, control system, drive system, display system, etc. all adopt high-reliability imported parts, with high precision, high efficiency, suitable for mass production, with international and domestic advanced level.



machine characteristics



main technical parameter


(1)

Electical servo bending

Max capacity

round tube/iron tube

( S=40kgf/mm )
100x3.6t
(2)Imported servo motor and reducer

Round tube/non iron metal tube

( S=25kgf/mm )
100x6.5t
(3)

Independent R & D software system

Round tube /stainless steel tube

( S=60kgf/mm )
100x2.4t
(4)1-6

layer die optional

Square tube/Metal Tube

( S=40kgf/mm )
70x70x3.5t
(5)11

axis full motor type optional

Round bar

( S=40kgf/mm )
45

Push-bending type, bending radius7D

Servo bending axis

precision

0.05

RBE strongly back push bending, minimum bending radius is 1D

max speed

65°/sec


Servo material feeding axis

precision

0.05mm


max speed

650mm/sec
RBE: 130mm/sec


Servo tube rotate axis

precision

0.05


max speed

120°/sec





Adapted material:steel pipe, stainless steel, copper pipe, aluminum pipe etc.



Recommended application industry:
automobile fittings ( oil pipe for brake, muffler, seats), motorcycle, healthy equipment, air-conditioning,bicycle, steel furniture, sanitary wares and so on.



Main features of CNC100REMP pipe bending machine:

  1. Operate by CNC control unit, imported electric and hydraulic elements.
  2. English showing and conversational operation.
  3. It can adjust speed in each bend and the bending precision is high.
  4. 16 groups of bending information can be stored. Multiple angles can be finished once.
  5. The foot switches with functions of automatic start, emergency stop and resuming.The safety is high.
  6. Delicate design of the bending head makes the bending space large.
  7. Suitable Materials: Steel pipe, stainless steel pipe, copper pipe, aluminum pipe and others.



FAQ


1. How to choose the pipe/tube bending machine?



You have to inform us following details:

- Max. outside diameter

- Wall thickness range

- Bending radius (CLR)

- The pipe material

- The drawings if possible



2. Do you provide any training to make sure our user can operate the machine very well?



1) We will provide detailed video and instruction book for this machine;

2) We also offer training in our factory to all the clients,and we will arrange everything for you during these days in our city,to make sure every client will be the expert in using our machine!



3. How long warranty can you provide?



Our machine warranty is one year,and we use all the stable compoenents with long working life!

And we can also send our technician to do the after-sale service in client's factory!



4. What kind of solution you can offer to make sure your pipe bending machine can do our job?



1) We will help you confirm the model of our machine according to your offered pipe information.

2) Before you start the order for this big value machine,you can offer your workpiece drawing to us.

We can design the tooling to make your products in our workshop,after you are sure that the workpiece is good,then we can confirm the order finally.

3) You can visit us to check how to bend your product before you start the order.During this period, you can also learn how to use this machine well!
