Product Details:
Payment & Shipping Terms:
|
| Maximum Bending Capacity: | 130x5.0mm | Round Tube/stainless Steel Tube: | 130x2.5mm |
|---|---|---|---|
| Square Tube/metal: | 90x6.0mm | Bending Radius: | 80~500mm |
| Bending Radius Range/square Tube: | 80~430mm | Bending Angle Range: | 190degree |
| Highlight: | Touch Screen CNC Tube Bending Machine,580mm/sec CNC Tube Bending Machine,Touch Screen Automatic Pipe Bending Machine |
||
CNC130REM+RBE High Precision Automatic Tube Bending Machine With Touch Screen Suitable For Stainless Steel Pipe
CNC130REM+RBE Tube Bender
Our high-efficiency 3d cnc automatic hydraulic pipe bender factory direct sales use industrial touch screen, simple English operation interface; high precision, high automation, and multi-function; every action of the machine is controlled by the PLC programmer control system or IPC (industrial personal computer) control.
Product parameter:
| machine characteristics | main technical parameter | ||
| (1) Electical servo bending | Max capacity | round tube/iron tube | Φ127x3.8t |
| ( S=40kgf/mm ) | |||
| (2) Imported servo motor and reducer | Round tube/non iron metal tube | Φ127x6.0t | |
| ( S=25kgf/mm ) | |||
| (3) Independent R & D software system | Round tube /stainless steel tube | Φ127x2.5t | |
| ( S=60kgf/mm ) | |||
| (4) 1-6 layer die optional | Square tube/Metal Tube | 90x90x3.5t | |
| ( S=40kgf/mm ) | |||
| (5) 11 axis full motor type optional | Round bar | Φ60 | |
| ( S=40kgf/mm ) | |||
| Push-bending type, bending radius7D | Servo bending axis | precision | 0.05 |
| RBE strongly back push bending, minimum bending radius is 1D | max speed | 65°/sec | |
| Servo material feeding axis | precision | 0.05mm | |
| max speed | 580mm/sec | ||
| RBE: 110mm/sec | |||
| Servo tube rotate axis | precision | 0.05 | |
| max speed | 100°/sec |
Recommended application industry:
Auto,motorbike,aircraft,bicycle,kids bike,fitness equipment,furniture,outdoor equipment,air conditioner,food machinery,nulcear tube such as reactor,evaporator and heat exchanger
Features of pipe bending machine:
1. Low cost for operator training,high production effeciency and product uniformity.
2. Drived by electric servo motors.compared with hydraulic drive,it has higher stability and longer lifetime.It is unnecessary to worry about oil-leak or working temperature.
3. Gapless tube bending,with long-time high precision and processing efficiency,easy for operation.It has good compatibility.
4. Small in size,low noise level.
5. Low running cost,with best cost performance for tube processing.
6. Widely used in small-diameter tube processing,for example tubes of air conditioner and oil tube for autos.
