Heavy Duty Semi Automatic Pipe Bending Machine Durable 85000kg CNC100RET-P

Large Image : Heavy Duty Semi Automatic Pipe Bending Machine Durable 85000kg CNC100RET-P

Product Details:

Place of Origin:	China
Brand Name:	YUANTAI
Certification:	CE
Model Number:	CNC100RET-P

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiatable
Packaging Details:	Standard export wooden case or pallet package

Contact Now

Detailed Product Description

Automation:	Semi Automatic	Machine Type:	Pipe And Tube Bending Machine
Control System:	Hydraulic Drive	Precision:	±0.05
Applications:	Fitness Equipment	CNC Control System:	PLC
Highlight:	industrial tube bender , 3d tube bending machine

CNC100RET-P Tube bender

Model
Taking the biggest bending radius 1.5D suitable for carbon steel tube material as example	￠100×3.5t
Max. effective distance of mandrel (a)	4800mm
Max. bending radius	350mm
Max. bending angle	195°
Oil pump	11KW
Bending drive system	gear and rack
Control system	PLC
Boost	Hydraulic
Cooling system	Water cooling
Weight	85000kg
L.W.H(cm)	7500×1900×1500

Function

2. New-designed camshaft is applied, which can eliminate wear clearance of gear and rack.

3. Forked-tail designed sliding block. Self-lubricating sliding components (oilless bearing).

4. Chinese display, HMI, manual/semi-automatic operation, movable pedal switch (start / emergency stop), two-way bent arm switch.

5. Hydraulic components are from famous suppliers.

6. Powerful cooling system for effective temperature control.

7. Easy operation, stable running, high efficiency, safe for operation.

Applications:

Auto,motorbike,aircraft,bicycle,kids bike,fitness equipment,furniture,outdoor equipment,air conditioner,food machinery,nulcear tube such as reactor,evaporator and heat exchanger

Advantages:

1, Microcomputer control, machine operation is very stable
2, With manual, automatic, semi-cycle, full cycle and other functions of arbitrary choice
3, 16 angle settings (0-185 degrees arbitrary), either single or two consecutive options
4, Mobile foot switch with three functions: automatic start, emergency stop, tight stop, high safety
5, Large capacity cooling cycle system, make the machine run more stable.
6, Die replacement is simple and convenient for flexible production.
7, The machine head, the tube bending design is exquisite, provides the maximum bend space.

Our Company:

Yuantai (Zhangjiagang) Machinery Technology Co., Ltd. is a leading technology enterprise specializing in the manufacture and development of CNC tube bending machines. Many kinds of CNC tube bender developed by the company are in the leading level at home and abroad and even in the world, reaching the world synchronous leading level.
The company independently developed the full-electric CNC tube bending machine control system is in the industry leading level, and obtained dozens of patents. Advanced techniques such as three-dimensional dynamic information simulation design and finite element force analysis are used in mechanical design.
