Product Details:
Payment & Shipping Terms:
|
| Module No.: | MC-425AC | Head Swivel: | 45° 90° R30° |
|---|---|---|---|
| Machine Weight: | 650kgs | Size: | 1300×1400×1900 |
| Material Feeding Precision: | ±0.1mm | Usage: | Tube Cuttings |
| Highlight: | aluminum cutting machine,cnc pipe cutting machine |
||
MC-425AC
| Main specification | |
| Saw blade drive motor | A:5HP/3HP 2/4 |
| Low 50HZ/60HZ 70/35rpm | |
| High 50HZ/60HZ 120/60rpm | |
| B:3HP | |
| 50HZ 35/20rpm | |
| 60HZ 42/23rpm | |
| Head Swivel | L45° 90° R30° |
| Cooling pump motor | 1/8HP 40W |
| Outer diameter | HSSΦ250-Φ425 Φ350 |
| Hydraulic Pump Motor | 2HP 4P |
| Size | 1300×1400×1900 |
| Pscking size(L×W×H) | 1460×820×2230 |
| Net weight | 650kgs |
| Gross weight | 850kgs |
| machine characteristics |
|
|
|
|
|
|
|
|
Applications:
Tube cuttings for Auto,motorbike,aircraft,bicycle,kids bike,fitness equipment,furniture,outdoor equipment,air conditioner,food machinery,nulcear tube such as reactor,evaporator and heat exchanger
Features
1. vertical slideway for advanced and retreat blade up and down.Cutting feed is steady and cutting tools are of long use life.High precision of saw cutting.
2. European design .multiple group of gear transmission is suitable to heavy cutting with steady precision
3. elaborate design of material feed system.The length of feed material can be set as 6-640m/mz(material feed can be divided into three times)
4. elaborate design of material feed floating system so as not to damage the surface of work piece and with high precision of material feed.
5. special main clamp design,the strength is solid
6. Slideway automatically add oil for lubricating,long use life of machine
7. Use PLC controller,no connected point,no fault and easy for maintenance
8. Cooling liquid automation circulation to ensure the smoothness of cutting surface of work piece.
9. centralized control button.Easy and simple operation.
10. Equipped with electric saw protection operation.
11. Equipped with electric saw cutting number setting and total number
12. Automatic stop when without material
13. Saw pieces are centralized for disposal which is convenient and clean
14. Digital displayer,easy fast and exact adjustment of length.
| machine characteristics |
|
|
|
|
|
|
|
|
