Product Details:
Payment & Shipping Terms:
|
| Module No.: | EF50D | Automation: | Automatic |
|---|---|---|---|
| Compressed Air: | 0.6-0.8MPa | Tube Diameter: | Φ8-50mm |
| Material Feeding Precision: | ±1mm | Speed: | Adjustable |
| Highlight: | automatic chamfering machine,double head chamfering machine |
||
EF50D double head chamfering machine
Main parameters
| Main parameter | EF50D |
| Process capacity(out diameter) | Φ8-50mm |
| Process length | short type |
| 18-100mm | |
| Standard type 80-550mm | |
| Prelong type 80-1000mm | |
| use compressed air | 0.6-0.8MPa |
Advantages:
| (1) The clamping die and the cutter head are carefully designed to ensure the accuracy of the machining objects and the center line of the cutter head. |
| (2) The inner and outer corners and the end face of the tube end can be processed uniformly at one time; |
| (3) the rotation speed can be adjusted, it is suitable for the processing of metal tubes with different materials; |
| (4) The Cutter head, clamp die replacement is simple and fast, suitable for elastic production. |
Application
Auto,motorbike,aircraft,bicycle,kids bike,fitness equipment,furniture,outdoor equipment,air conditioner,food machinery,nulcear tube such as reactor,evaporator and heat exchanger
Features
1. Automatic 3D simulation function for detecting interferring position is selected as required.
2. All processing data are inputted by the touch screen
3. Based on the change of materials,each curve is set with a compensation value,a speed and a demoulding gap.
4. Each curve of one tube can be programmed with five action sequences and ten-stage speeds,so that the processing efficiency is improved,and the interference point is reduced.
5. Chinese/English language are switched to display on the touch screen,and customers can also purchase the machine installed with other languages
6. The feeding mode comprises the clamping feeding mode or the direct feeding mode which is selected as required.
7. The X.Y.Z coordinate can be automatically switched into the Y.B.C processing values
8. After the data are compiled,the data is protected by a key,so that the data are prevented from any modification.
9. The electric control system is equipped with a heat exchanger for automatic heat dissipation;if necessary,a numerical control type refrigerator can be additionally bought,so that the life span of the electric control system is ensured.
10. An automatic oil charging system is installed to reduce friction of the bending tube.It prolongs the lifetime of the core rod and improves the quality of the bended tube.
