Product Details:
Payment & Shipping Terms:
|
| Module No.: | EF80AC | Automation: | Automatic |
|---|---|---|---|
| Compressed Air: | 0.6-0.9MPa | Tube Diameter: | φ20-80 |
| Material Feeding Precision: | ±1mm | Machine Size: | 800×750×1350 |
| Highlight: | automatic chamfering machine,double head chamfering machine |
||
70 NC Metal fast precision cutting machine
Main parameters
| Model : | EF80AC |
| Process Capacity | tube diameter |
| φ20-80 | |
| round bar | |
| φ6-38 | |
| Main motor | 2.2*6P |
| Use blade | φ20-80 |
| Compress air | 0.6-0.9MPa |
| 120ml/min | |
| Machine weight | 380kg |
| Machine size | 800×750×1350 |
Advantages:
1. Manually material feed, automatic gripping, automatic knife feed and back, fast speed, increase output;
2. the cutting and chamfering speed can be adjusted
3. Cutter head, clamp die replacement is simple and fast, suitable for elastic production.
4. Well designed clamp and a cutter head,unchanged center lines of the processing target
Applications:
Auto,motorbike,aircraft,bicycle,kids bike,fitness equipment,furniture,outdoor equipment,air conditioner,food machinery,nulcear tube such as reactor,evaporator and heat exchanger
Features
1. The electric control system uses famous Japanese controllers,such as servo drivers,servo motors,positioning modules and CPUs manufatured by the Mitsubishi Corporation,and is high in performance and good stability.
2. The Mitsubishi ultra-large CPU can accommodate 400 groups of files for compiling,if necessary,the additional transmission software is bought and installed in the computer,and the documents and files are stored in the hard disk,so that the number of compiling groups is unlimitedly expanded.
3. Industrial-use computer type:the WINDOWS operating system is internally installed,and used together with the Mitsubishi servo system,besides the Mitsubishi servo driving,the convenient file management owned by the WINDOWS operating system is also provided;and the files can be storted in the hard disk or soft disk,so that the compiling groupnumber is unlimitedly expanded.
4. Automatic 3D simulation function for tube-forming is selected as required.
5. An automatic error-fault detecting function is provided,and the errors and faults are displayed on the screen,so that the operator can much easily troubleshoot.
6. Automatic 3D simulation function for detecting interferring position is selected as required.
7. All processing data are inputted by the touch screen
8. Based on the change of materials,each curve is set with a compensation value,a speed and a demoulding gap.
9. Each curve of one tube can be programmed with five action sequences and ten-stage speeds,so that the processing efficiency is improved,and the interference point is reduced.
10. Chinese/English language are switched to display on the touch screen,and customers can also purchase the machine installed with other languages
