Industrial Pipe End Forming Machine TM-15T Suit For Small Diameter Tube end expand or reduce

Large Image : Industrial Pipe End Forming Machine TM-15T Suit For Small Diameter Tube end expand or reduce

Product Details:

Place of Origin:	China
Brand Name:	YUANTAI
Certification:	CE
Model Number:	TM-15T

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiatable
Packaging Details:	Standard export wooden case or pallet package

Contact Now

Detailed Product Description

Module No.:	TM-15T	Hydraulic Power:	20 Ton
Max Suitable Tube Size:	Φ80	Max Working Stroke:	160mm
Station:	4 Or 6	Working Speed:	3-4 Sec
Highlight:	tube end forming equipment , hydraulic tube end forming machines

main technical parameter
Max suitable tube size	Φ80
Max working stroke	160mm
Hydraulic power	20Ton
Station	4 or 6
Servo Die change speed	0.05mm
working speed	3-4sec

Machine characteristics

(1) PLC control, hydraulic drive, stable operation

(2) Touch screen control

(3) Mobile pedal switch with automatic, tight stop,continue three consecutive modes

(4) Four / six station, servo die changing, high speed and precision

(5) Die replacement is simple and suitable for elastic production

(6) Can shrink tube, expand tube, tampering process.

Advantages:

1. Low cost for operator training,high production effeciency and product uniformity.

2. Drived by electric servo motors.compared with hydraulic drive,it has higher stability and longer lifetime.It is unnecessary to worry about oil-leak or working temperature.

3. Gapless tube bending,with long-time high precision and processing efficiency,easy for operation.It has good compatibility.

4. Small in size,low noise level

5. Low running cost,with best cost performance for tube processing.

6. Widely used in small-diameter tube processing,for example tubes of air conditioner and oil tube for autos

Standard models:1~5 stacks,4~6 servo motors

Advanced motor:11 fully electric servo motors

FAQ

1. How to choose the pipe/tube bending machine?

You have to inform us following details:
- Max. outside diameter
- Wall thickness range
- Bending radius (CLR)
- The pipe material
- The drawings if possible

2. Do you provide any training to make sure our user can operate the machine very well?

1) We will provide detailed video and instruction book for this machine;
2) We also offer training in our factory to all the clients,and we will arrange everything for you during these days in our city,to make sure every client will be the expert in using our machine!

3. How long warranty can you provide?

Our machine warranty is one year,and we use all the stable compoenents with long working life!
And we can also send our technician to do the after-sale service in client's factory!
